N3150機配Realtek LAN,響FreeBSD/pfSense真係災難

本帖最後由 kennylam777 於 2016-4-27 03:48 編輯

我部n3150之前都講過。
微分享: N3150無風扇主機做x86 router with pfSense 2.2.5
http://www.hkepc.com/forum/viewthread.php?fid=12&tid=2240827

早排認真試部N3150, iperf3太低而且成日唔穩定,開頭以為係hardware failure,但換咗返黎問題都係一樣,就懷疑係咪Realtek夾FreeBSD有問題....一試,死火。

Realtek GbE配pfSense 2.2.6, 可以見到斷traffic,console顯示直頭熄port顯示"re0: watchdog timeout"


Realtek GbE配Ubuntu 16.04 Linux,冇斷traffic一直打爆GbE port


鬼佬一樣有同樣問題: https://forums.freenas.org/index ... .24052/#post-147189
The bigger problems with Realtek and Atheros are not throughput (although some do hate the poor throughput). The problems are that they randomly just stop working. People will take 80MB/sec over 0MB/sec any day.
FreeNAS一樣係FreeBSD,同一命運。

FreeBSD 10.2一樣死法,一樣n3150 https://forums.freebsd.org/threads/55861/
However, the network has been very unstable with poor throughput and many NIC driver restarts (ie, "re0: watchdog timeout"). It has no expansion slots, so a replacement NIC is not an option.

最慘係,我試埋所有FreeBSD tunable,亦試埋pfSense 2.3,一樣死。

由於我要行VPN,要快嘅OpenVPN同IPSec,好需要AES-NI又好想用pfSense,所以解決方法係扯個mini PCI-e出黎拉Intel卡,之後再貼安裝過程上黎。

如果各位打算行Linux/Windows的話,Realtek都算正常用得,要用pfSense行n3150賺AES-NI的話,我建議大家買塊有3條PCI-E槽嘅n3150板 (x16 + x1 + x1),再配返Intel多port卡免麻煩。
附件: 您需要登錄才可以下載或查看附件。沒有帳號?註冊

Realtek? No way.

TOP

回覆 1# kennylam777

想請教點樣扯個mini PCI-e出黎拉Intel卡?

TOP

回覆  kennylam777

想請教點樣扯個mini PCI-e出黎拉Intel卡?
雯雯 發表於 2016-4-27 09:22


mini-pcie lan card or mini-pcie to pcie adapter

TOP

唉,我嗰時又係間唔屎 watchdog timeout, 搞到用 clearOS, 原來係 realtek 唔夾,但係好似係新 pfsense version 先係咁,以前 version 我用過好似冇呢個問題。。?

TOP

mini-pcie to pcie adapter 要另外配12V去供電

TOP

本帖最後由 marcolee1314 於 2016-4-27 12:19 編輯
唉,我嗰時又係間唔屎 watchdog timeout, 搞到用 clearOS, 原來係 realtek 唔夾,但係好似係新 pfsense ver ...
dinobb 發表於 2016-4-27 12:10



我由2.2用到2.2.6都有咁既問題
Realtak同FreeBSD有咁既問題架
我個opt1係realtek 8111g
開左controlflow好左好多無出咁多re0: watchdog timeout
呀, 好似仲要加幾句code
你都試試

https://forum.pfsense.org/index.php?topic=101587.0;topicseen

附件: 您需要登錄才可以下載或查看附件。沒有帳號?註冊

TOP

本帖最後由 kennylam777 於 2016-4-27 12:35 編輯
mini-pcie to pcie adapter 要另外配12V去供電
dchyhk 發表於 2016-4-27 12:16


唔緊要啦本來部機就有12V input, 分多個出黎。

我由2.2用到2.2.6都有咁既問題
Realtak同FreeBSD有咁既問題架
我個opt1係realtek 8111g
開左con ...
marcolee1314 發表於 2016-4-27 12:17


試過flow control冇用, Half-duplex就有但會跌速至500Mbps。果幾句loader tunables都係冇效果......
有時間我試下FreeBSD 11果個新driver同埋Realtek official driver,有改善就考慮下back ports

TOP

差 d 想去淘占美 N3150 玩 pfsense, 要觀察下先

TOP

認真,Realtek 既卡從來都無真係係 *nix 好過架喎
Supermicro C2358 向樓主揮手中
