作者: kbpaul 時間: 昨天 15:21 標題: win 7->10 經常出現dpc_watchdog_violation
本帖最後由 kbpaul 於 2026-9-3 15:27 編輯
行winDbg睇memery dump file，分析如下
DPC_WATCHDOG_VIOLATION (133)
The DPC watchdog detected a prolonged run time at an IRQL of DISPATCH_LEVEL
or above.
Arguments:
Arg1: 0000000000000000, A single DPC or ISR exceeded its time allotment. The offending
component can usually be identified with a stack trace.
Arg2: 0000000000000501, The DPC time count (in ticks).
Arg3: 0000000000000500, The DPC time allotment (in ticks).
Arg4: fffff80704cfb320, cast to nt!DPC_WATCHDOG_GLOBAL_TRIAGE_BLOCK, which contains
additional information regarding this single DPC timeout
Debugging Details:
------------------
*** WARNING: Unable to verify timestamp for echo1394.sys
*************************************************************************
*** ***
*** ***
*** Either you specified an unqualified symbol, or your debugger ***
*** doesn't have full symbol information. Unqualified symbol ***
*** resolution is turned off by default. Please either specify a ***
*** fully qualified symbol module!symbolname, or enable resolution ***
*** of unqualified symbols by typing ".symopt- 100". Note that ***
*** enabling unqualified symbol resolution with network symbol ***
*** server shares in the symbol path may cause the debugger to ***
*** appear to hang for long periods of time when an incorrect ***
*** symbol name is typed or the network symbol server is down. ***
*** ***
*** For some commands to work properly, your symbol path ***
*** must point to .pdb files that have full type information. ***
*** ***
*** Certain .pdb files (such as the public OS symbols) do not ***
*** contain the required information. Contact the group that ***
*** provided you with these symbols if you need this command to ***
*** work. ***
*** ***
*** Type referenced: TickPeriods ***
*** ***
*************************************************************************
KEY_VALUES_STRING: 1
Key : Analysis.CPU.mSec
Value: 3281
Key : Analysis.Elapsed.mSec
Value: 6457
Key : Analysis.IO.Other.Mb
Value: 0
Key : Analysis.IO.Read.Mb
Value: 1
Key : Analysis.IO.Write.Mb
Value: 0
Key : Analysis.Init.CPU.mSec
Value: 671
Key : Analysis.Init.Elapsed.mSec
Value: 4912
Key : Analysis.Memory.CommitPeak.Mb
Value: 87
Key : Analysis.Version.DbgEng
Value: 10.0.29617.1000
Key : Analysis.Version.Description
Value: 10.2604.29.1 amd64fre
Key : Analysis.Version.Ext
Value: 1.2604.29.1
Key : Bugcheck.Code.LegacyAPI
Value: 0x133
Key : Bugcheck.Code.TargetModel
Value: 0x133
Key : Failure.Bucket
Value: 0x133_DPC_ks!CKsQueue::UnlockStreamPointer
Key : Failure.Hash
Value: {53605990-ed08-1cb4-4fe1-2560485dee2d}
Key : Stack.Pointer
Value: ISR
Key : WER.OS.Branch
Value: vb_release
Key : WER.OS.Version
Value: 10.0.19041.1
Key : WER.System.BIOSRevision
Value: 3.96.0.0
BUGCHECK_CODE: 133
BUGCHECK_P1: 0
BUGCHECK_P2: 501
BUGCHECK_P3: 500
BUGCHECK_P4: fffff80704cfb320
FILE_IN_CAB: 090126-21562-01.dmp
FAULTING_THREAD: fffff80704d27a00
DPC_TIMEOUT_TYPE: SINGLE_DPC_TIMEOUT_EXCEEDED
TRAP_FRAME: fffff807088a8540 -- (.trap 0xfffff807088a8540)
NOTE: The trap frame does not contain all registers.
Some register values may be zeroed or incorrect.
rax=0000000000000002 rbx=0000000000000000 rcx=ffff8007f26f4120
rdx=ffff8007f26f4120 rsi=0000000000000000 rdi=0000000000000000
rip=fffff807042d89fa rsp=fffff807088a86d0 rbp=ffff8007f06d0010
r8=0000000000000000 r9=0000000000000000 r10=fffff807042d89e0
r11=ffffd57daf400000 r12=0000000000000000 r13=0000000000000000
r14=0000000000000000 r15=0000000000000000
iopl=0 nv up ei ng nz na po nc
nt!KeAcquireSpinLockRaiseToDpc+0x1a:
fffff807`042d89fa 8b05603ca200 mov eax,dword ptr [nt!KiIrqlFlags (fffff807`04cfc660)] ds:fffff807`04cfc660=????????
Resetting default scope
BLACKBOXBSD: 1 (!blackboxbsd)
BLACKBOXNTFS: 1 (!blackboxntfs)
BLACKBOXPNP: 1 (!blackboxpnp)
BLACKBOXWINLOGON: 1 (!blackboxwinlogon) (!blackboxwinlogonnotify)
CUSTOMER_CRASH_COUNT: 1
PROCESS_NAME: System
STACK_TEXT:
fffff807`088b6c88 fffff807`04426b7a : 00000000`00000133 00000000`00000000 00000000`00000501 00000000`00000500 : nt!KeBugCheckEx
fffff807`088b6c90 fffff807`042275ed : 001e8555`58f9f1ca fffff807`0049c180 00000000`00000246 00000000`00854488 : nt!KeAccumulateTicks+0x2027aa
fffff807`088b6cf0 fffff807`04227b91 : ffff8007`eb002000 00000000`004f6f09 fffff807`0049c180 00000000`00000001 : nt!KiUpdateRunTime+0x5d
fffff807`088b6d40 fffff807`042218e3 : fffff807`0049c180 00000000`00000000 fffff807`04c31980 00000000`00000000 : nt!KiUpdateTime+0x4a1
fffff807`088b6e80 fffff807`04229fe2 : fffff807`088a8540 fffff807`088a85c0 fffff807`088a8500 00000000`00000002 : nt!KeClockInterruptNotify+0x2e3
fffff807`088b6f30 fffff807`04343a65 : 0000013d`bc3ceda6 fffff807`04cf3da0 fffff807`04cf3e50 ffff6fed`7e604732 : nt!HalpTimerClockInterrupt+0xe2
fffff807`088b6f60 fffff807`043ff5fa : fffff807`088a85c0 fffff807`04cf3da0 00000000`00000000 00000000`00000000 : nt!KiCallInterruptServiceRoutine+0xa5
fffff807`088b6fb0 fffff807`043ffe27 : ffff8007`f5934100 fffff807`043ffe34 fffff807`043f9670 fffff807`042eed8a : nt!KiInterruptSubDispatchNoLockNoEtw+0xfa
fffff807`088a8540 fffff807`042d89fa : 00000000`00000000 00000000`00000000 00000000`00000000 ffffd57d`af400000 : nt!KiInterruptDispatchNoLockNoEtw+0x37
fffff807`088a86d0 fffff80d`3ced1614 : ffff8007`f5934170 ffff8007`f5934170 ffff8007`f26f4010 fffff80d`3cedeac0 : nt!KeAcquireSpinLockRaiseToDpc+0x1a
fffff807`088a8700 fffff80d`3ced6a23 : 00000000`00000000 00000000`00000000 00000000`00000000 fffff80d`3ced4104 : ks!CKsQueue::UnlockStreamPointer+0x164
fffff807`088a87a0 fffff80d`28fe1df9 : ffffe581`137d46f0 00000000`00000000 00000000`00000008 ffff8007`d5efb000 : ks!KsStreamPointerAdvanceOffsetsAndUnlock+0xd3
fffff807`088a87f0 ffffe581`137d46f0 : 00000000`00000000 00000000`00000008 ffff8007`d5efb000 ffff8007`d5579f70 : echo1394+0x1df9
fffff807`088a87f8 00000000`00000000 : 00000000`00000008 ffff8007`d5efb000 ffff8007`d5579f70 00000000`00000000 : 0xffffe581`137d46f0
SYMBOL_NAME: ks!CKsQueue::UnlockStreamPointer+164
MODULE_NAME: ks
IMAGE_NAME: ks.sys
IMAGE_VERSION: 10.0.19041.6389
STACK_COMMAND: .process /r /p 0xfffff80704d24a00; .thread /r /p 0xfffff80704d27a00 ; kb
BUCKET_ID_FUNC_OFFSET: 164
FAILURE_BUCKET_ID: 0x133_DPC_ks!CKsQueue::UnlockStreamPointer
OS_VERSION: 10.0.19041.1
BUILDLAB_STR: vb_release
OSPLATFORM_TYPE: x64
OSNAME: Windows 10
FAILURE_ID_HASH: {53605990-ed08-1cb4-4fe1-2560485dee2d}
Followup: MachineOwner
---------
有無師兄知係什么原因
參考:echo1394.sys係echo audiofire4(firewire) audio interface驅動程式
作者: cyberyeah 時間: 昨天 18:16
影張相比AI問喇
