免費Azure Sphere

本帖最後由 buffaloxxx 於 2019-9-17 20:52 編輯

https://www.element14.com/community/groups/azuresphere#?ICID=azure-sphereCH-mobile

登記後有免费Code
要比運費HK$36

1

0

hon829

進階會員

Rank: 3 Rank: 3 Rank: 3

2^#

發表於 2019-9-18 12:32 | 只看該作者

要不要開户租用Azure服務

感覺微軟之前的Windoes 10 IoT 系統都沒什氣息, 這新產物還是...

TOP

buffaloxxx

中級會員

Rank: 2 Rank: 2

3^#

發表於 2019-9-18 18:14 | 只看該作者

根據microsft資訊沒有其他費用
Azure Sphere does not require you to pay any ongoing fees. The one-time cost you pay for your MCU chip includes access to the Azure Sphere OS, Azure Sphere Security Service, and OS updates for the lifetime of your chip.

TOP

Offer

Moderator

Rank: 7 Rank: 7 Rank: 7 Rank: 7 Rank: 7 Rank: 7 Rank: 7

4^#

發表於 2019-9-19 17:10 | 只看該作者

本帖最後由 Offer 於 2019-9-20 13:21 編輯

已經order左的朋友可以考慮组成project team一齊玩下

https://azure.microsoft.com/zh-tw/services/azure-sphere/

Features

Carrier Board
Two MikroE Click board expansion sockets
Grove expansion connector (I2C)
On-board sensors
3-Axis accelerometer
3-Axis gyro
Temperature
Pressure/Barometric
Ambient Light
Interface for optional OLED 128x64 display
USB Interface
Supports debug, service & recovery UARTs, and JTAG
User pushbutton switches and LEDs
5V to 3.3V Power regulation
DC Supply Input:
USB 5V from host computer
Terminal footprints for external 5V DC and VBAT supplies

Azure Sphere MT3620 Module
MT3620AN SoC
3x ISU interfaces pre-configured for UART, SPI, I2C
ADC/GPIO: 3x 12-bit ADC inputs (or 3 GPIOs)
PWM/GPIO: 9x PWM outputs (or up to 24 GPIOs)
RTC (requires VBAT supply)
Dual-band 2.4/5GHz 802.11 a/b/g/n Wi-Fi
Dual-band 2.4/5GHz chip antenna

TOP
